Heavy Load Suspension Type Bridge Structural Steel Bridge Custom Made

Name: Heavy Load Suspension Type Bridge Structural Steel Bridge Custom Made
Brand: EVERCROSS BRIDGE TECHNOLOGY (SHANGHAI) CO.,LTD.
SKU: COMPACT-200; COMPACT-100; CHINA 321 ; PB 100; LSB; GWD; DELTA; 450,etc
Price: 1,500.00 USD
Availability: InStock

Brand Name:	EVERCROSS
Model Number:	COMPACT-200; COMPACT-100; CHINA 321 ; PB 100; LSB; GWD; DELTA; 450,etc
MOQ:	negotiation
Price:	1000USD ~ 2000USD Per ton
Delivery Time:	negotiation
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CNAS; COC; PVOC; SONCAP; CIDB;FORM E;FORM L; FORM M, etc

Product Name:

Steel Cable Suspension Bridge

Material:

Steel

Spans:

Large Spans

Type:

Suspension Bridges

Usage:

Heavy Loading, Railway Traffic

Decking Material:

Steel Concrete

Packaging Details:

According to detailed order

Highlight:

Custom Made Suspension Type Bridge

Structural Steel Bridge Custom Made

Structural Steel Suspension Type Bridge

Product Description

Heavy Load Suspension Type Bridge Structural Steel Bridge Custom Made

Product Name	Steel Cable Suspension Bridge
Material	Steel
Spans	Large Spans
Type	Suspension Bridges
Usage	Heavy Loading, Railway Traffic
Decking Material	Steel Concrete

Steel Cable Suspension Bridge Overview

The Steel Cable Suspension Bridge is a flexible suspension combination system composed of a main cable and stiffened beam, combining the stress characteristics of both cable and beam structures. This bridge type is particularly suitable for spans greater than 1000m.

Structural Components

Main Cable

The primary load-bearing component that deforms under load, directly affecting the bridge's internal force and deformation. Available in two types:

Wire rope main cable: Twisted strands used for smaller span bridges
Parallel wire bundle main cable: Prefabricated parallel steel wire strands for larger spans

Bridge Tower

The main vertical support structure that resists vertical loads. Available in three structural forms:

Rigid tower (small horizontal displacement)
Flexible tower (larger horizontal displacement)
Rocking column tower (for small spans)

Stiffening Beam

Provides structural stiffness and ensures vehicle running stability. Available in multiple forms:

Steel truss beams
Steel box beams
Concrete beams
Steel-mixed composite beams

Anchorage Systems

Transmits main cable tension to the foundation. Two primary types:

Gravity anchorage: Suitable for nearly all conditions
Tunnel anchorage: More economical when geological conditions permit

Classification

By Suspension Span Count

Single-span suspension bridge
Three-span suspension bridge
Four-span suspension bridge
Five-span suspension bridge

By Main Cable Anchoring

Ground anchor: Tension transferred to foundation
Self-anchoring: Tension transferred directly to stiffening beam

Protection Design

Concrete Structure Protection

Increased concrete protective layer thickness
High performance durable concrete
Protective coatings and sealants
Improved reinforcement materials
Cathodic protection systems

Steel Structure Protection

Advanced paint coating systems
Thermal spray metal coatings
Use of weathering steel
Environmental improvements

Key Advantages

Superior span capacity (1000m+)
Excellent seismic performance
Lightweight yet strong structure
Inherent flexibility for dynamic load absorption
Faster construction compared to other bridge types

Evercross Steel Bridges Specifications

Product Range	Bailey bridge (Compact-200, Compact-100, LSB, PB100, China-321, BSB) Modular bridge (GWD, Delta, 450-type, etc.) Truss Bridge, Warren bridge Arch bridge, Plate bridge, Beam bridge, Box girder bridge Suspension bridge, Cable-stayed bridge Floating bridge, etc.
Design Spans	10M TO 300M Single span
Carriage Way	SINGLE LANE, DOUBLE LANES, MULTILANE, WALKWAY, ETC
Loading Capacity	AASHTO HL93.HS15-44, HS20-44, HS25-44 BS5400 HA+20HB, HA+30HB AS5100 Truck-T44 IRC 70R Class A/B NATO STANAG MLC80/ MLC110 Truck-60T, Trailer-80/100Ton, etc.
Steel Grade	EN10025 S355JR S355J0/EN10219 S460J0/ EN10113 S460N/BS4360 Grade 55C AS/ NZS3678/ 3679/ 1163/ Grade 350 ASTM A572/A572M GR50/GR65 GB1591 GB355B/C/D/460C, etc.
Certificates	ISO9001, ISO14001, ISO45001, EN1090, CIDB, COC, PVOC, SONCAP, etc.
