Heavy Loading Steel Cable Suspension Bridge With Steel Concrete Decking

Name: Heavy Loading Steel Cable Suspension Bridge With Steel Concrete Decking
Brand: EVERCROSS BRIDGE TECHNOLOGY (SHANGHAI) CO.,LTD.
SKU: COMPACT-200; COMPACT-100; CHINA 321 ; PB 100; LSB; GWD; DELTA; 450,etc
Price: 1,500.00 USD
Availability: InStock

Brand Name:	EVERCROSS
Model Number:	COMPACT-200; COMPACT-100; CHINA 321 ; PB 100; LSB; GWD; DELTA; 450,etc
MOQ:	negotiation
Price:	1000USD ~ 2000USD Per ton
Delivery Time:	negotiation
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CNAS; COC; PVOC; SONCAP; CIDB;FORM E;FORM L; FORM M, etc

Product Name:

Steel Cable Suspension Bridge

Material:

Steel

Spans:

Large Spans

Type:

Suspension Bridges

Usage:

Heavy Loading, Railway Traffic

Decking Material:

Steel Concrete

Packaging Details:

According to detailed order

Highlight:

Heavy Loading Steel Cable Suspension Bridge

Concrete Decking Steel Cable Suspension Bridge

Concrete Decking steel wire bridge

Product Description

Heavy Loading Steel Cable Suspension Bridge With Steel Concrete Decking

Key Specifications

Attribute	Value
Product Name	Steel Cable Suspension Bridge
Material	Steel
Spans	Large Spans
Type	Suspension Bridges
Usage	Heavy Loading, Railway Traffic
Decking Material	Steel Concrete

Structural Overview

The Steel Cable Suspension Bridge is a flexible suspension combination system composed of a main cable and stiffened beam, combining the stress characteristics of both cable and beam structures. This engineering solution is particularly effective for large span applications exceeding 1000 meters.

Primary Components

Suspension Cables: High-strength steel cables following a catenary curve to efficiently distribute bridge loads
Towers/Pylons: Tall structures supporting suspension cables and resisting vertical/horizontal forces
Anchorages: Massive foundations securing suspension cables and resisting tension forces
Hangers: Connecting elements that suspend the bridge deck from main cables
Bridge Deck: Steel concrete roadway surface designed for heavy loading
Tower Stiffening Systems: Additional bracing elements enhancing stability against wind and dynamic loads

Load Characteristics

The load path transmits forces from slings to cables, then to anchors, piers, and towers. Both main cables and stiffened beams share the load-bearing responsibility. The main cable serves as the primary load-bearing component, experiencing deformation under load while maintaining structural integrity.

Bridge Tower Configurations

Bridge towers are designed in three structural forms based on mechanical properties:

Rigid Tower: Minimal horizontal displacement at the top
Flexible Tower: Significant horizontal displacement capability
Rocking Column Tower: Hinged single-column structure for smaller spans

Stiffening Beam Types

Various stiffened beam configurations ensure structural performance:

Steel truss beams
Steel box beams
Concrete beams
Steel-mixed composite beams

Classification Systems

By Span Count:

Single-span suspension bridge
Three-span suspension bridge
Four-span suspension bridge
Five-span suspension bridge

By Cable Anchoring:

Ground Anchorage: Tension transferred to foundation via gravity or tunnel anchors
Self-Anchoring: Tension transmitted directly to stiffening beam

Construction Process

The systematic construction sequence ensures structural integrity:

Anchor foundation construction
Anchor construction
Bridge tower foundation work
Tower erection
Main cable installation
Stiffened beam assembly
Bridge deck completion

Protection Systems

Concrete Structure Protection:

Increased concrete protective layer thickness
High-performance durable concrete formulations
Protective coatings and sealing layers
Enhanced reinforcement materials and coatings
Cathodic protection systems

Steel Structure Protection:

Advanced paint coating systems
Thermal spray zinc/aluminum alloy coatings
Weathering steel applications
Environmental control measures

Engineering Advantages

Structural Efficiency: Optimal material usage through tension force distribution
Flexibility: Dynamic adaptation to wind, seismic, and traffic loads
Long-Span Capability: Ideal for spans exceeding 1000 meters
Lightweight Construction: Reduced foundation requirements
Aesthetic Appeal: Iconic architectural presence

Evercross Steel Bridges Specifications

Category	Specifications
Bridge Types	Bailey bridge, Modular bridge, Truss Bridge, Warren bridge, Arch bridge, Plate bridge, Beam bridge, Box girder bridge, Suspension bridge, Cable-stayed bridge, Floating bridge
Design Spans	10M to 300M Single span
Carriage Way	Single lane, Double lanes, Multilane, Walkway
Loading Capacity	AASHTO HL93.HS15-44, HS20-44, HS25-44, BS5400 HA+20HB, HA+30HB, AS5100 Truck-T44, IRC 70R Class A/B, NATO STANAG MLC80/MLC110, Truck-60T, Trailer-80/100Ton
Steel Grade	EN10025 S355JR S355J0/EN10219 S460J0/EN10113 S460N/BS4360 Grade 55C, AS/NZS3678/3679/1163 Grade 350, ASTM A572/A572M GR50/GR65, GB1591 GB355B/C/D/460C
Certifications	ISO9001, ISO14001, ISO45001, EN1090, CIDB, COC, PVOC, SONCAP
