Highway Steel Cable Suspension Bridges Long Life Four Span Five Span

Name: Highway Steel Cable Suspension Bridges Long Life Four Span Five Span
Brand: EVERCROSS BRIDGE TECHNOLOGY (SHANGHAI) CO.,LTD.
SKU: COMPACT-200; COMPACT-100; CHINA 321 ; PB 100; LSB; GWD; DELTA; 450,etc
Price: 1,500.00 USD
Availability: InStock

Brand Name:	EVERCROSS
Model Number:	COMPACT-200; COMPACT-100; CHINA 321 ; PB 100; LSB; GWD; DELTA; 450,etc
MOQ:	negotiation
Price:	1000USD ~ 2000USD Per ton
Delivery Time:	negotiation
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CNAS; COC; PVOC; SONCAP; CIDB;FORM E;FORM L; FORM M, etc

Product Name:

Steel Cable Suspension Bridge

Material:

Steel

Spans:

Large Spans

Type:

Suspension Bridges

Usage:

Heavy Loading, Railway Traffic

Decking Material:

Steel Concrete

Packaging Details:

According to detailed order

Highlight:

Highway Steel Cable Suspension Bridges

Long Life steel cable bridge

Five Span steel wire bridge

Product Description

Highway Steel Cable Suspension Bridges - Long Life Four Span & Five Span

Product Specifications

Attribute	Value
Product Name	Steel Cable Suspension Bridge
Material	Steel
Spans	Large Spans
Type	Suspension Bridges
Usage	Heavy Loading, Railway Traffic
Decking Material	Steel Concrete

Structural Overview

The Steel Cable Suspension Bridge is a flexible suspension system combining a main cable and stiffened beam, featuring the stress characteristics of both components. This permanent structure consists of several key elements:

Load Characteristics

Load transmission flows from slings to the main cable, then to anchors, piers, and towers. Both main cable and stiffened beam share the load-bearing responsibility:

Main Cable: Primary load-bearing component that deforms under load, affecting bridge's internal force and deformation
Bridge Tower: Main vertical load-bearing structure
Stiffening Beam: Secondary structure ensuring vehicle stability and providing stiffness
Anchor: Transmits main cable tension to foundation

Main Cable Types

Wire Rope Main Cable: 7-strand construction for smaller spans
Parallel Wire Bundle Main Cable: Prefabricated parallel steel wire strands (PPWS method) for faster construction

Bridge Tower Design

Three structural forms available:

Rigid Tower: Minimal horizontal displacement
Flexible Tower: Significant horizontal displacement
Rocking Column Tower: Hinged single-column for small spans

Stiffening Beam Options

Multiple structural forms available to suit project requirements:

Steel truss beams
Steel box beams
Concrete beams
Steel-concrete composite beams

Classification by Span Configuration

Single-span suspension bridge
Three-span suspension bridge
Four-span suspension bridge
Five-span suspension bridge

Key Advantages

Superior span capacity (1000m+)
Excellent seismic performance
Lightweight yet strong structure
Durable long-life construction

Protection Systems

Concrete Structure Protection:

Increased concrete protective layer thickness
High performance durable concrete
Protective coatings and sealants
Corrosion inhibitors

Steel Structure Protection:

Advanced paint coating systems
Thermal spray zinc/aluminum alloys
Weathering steel options
Environmental control measures

Evercross Steel Bridges Specifications

Category	Specifications
Bridge Types	Bailey bridge (Compact-200, Compact-100, LSB, PB100, China-321, BSB), Modular bridge (GWD, Delta, 450-type), Truss Bridge, Warren bridge, Arch bridge, Plate bridge, Beam bridge, Box girder bridge, Suspension bridge, Cable-stayed bridge, Floating bridge
Design Spans	10M to 300M Single span
Carriage Way	SINGLE LANE, DOUBLE LANES, MULTILANE, WALKWAY
Loading Capacity	AASHTO HL93.HS15-44, HS20-44, HS25-44, BS5400 HA+20HB, HA+30HB, AS5100 Truck-T44, IRC 70R Class A/B, NATO STANAG MLC80/ MLC110, Truck-60T, Trailer-80/100Ton
Steel Grade	EN10025 S355JR S355J0/EN10219 S460J0/ EN10113 S460N/BS4360 Grade 55C, AS/NZS3678/3679/1163/Grade 350, ASTM A572/A572M GR50/GR65, GB1591 GB355B/C/D/460C
Certificates	ISO9001, ISO14001, ISO45001, EN1090, CIDB, COC, PVOC, SONCAP
