Custom Made Cable Supported Bridge Prefabricated Steel Truss Bridge

Name: Custom Made Cable Supported Bridge Prefabricated Steel Truss Bridge
Brand: EVERCROSS BRIDGE TECHNOLOGY (SHANGHAI) CO.,LTD.
SKU: COMPACT-200; COMPACT-100; CHINA 321 ; PB 100; LSB; GWD; DELTA; 450,etc
Price: 1,500.00 USD
Availability: InStock

Brand Name:	EVERCROSS
Model Number:	COMPACT-200; COMPACT-100; CHINA 321 ; PB 100; LSB; GWD; DELTA; 450,etc
MOQ:	negotiation
Price:	1000USD ~ 2000USD Per ton
Delivery Time:	negotiation
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CNAS; COC; PVOC; SONCAP; CIDB;FORM E;FORM L; FORM M, etc

Product Name:

Cable-stayed Bridge

Material:

Steel

Spans:

Large Span

Type:

Steel Truss Bridge

Usage:

Permanent Bridge

Length / Width:

Customized

Packaging Details:

According to detailed order

Highlight:

Custom made cable supported bridge

Custom Prefabricated Steel Truss Bridge

Product Description

Custom Made Cable Supported Bridge Prefabricated Steel Truss Bridge

Product Specifications

Attribute	Value
Product Name	Cable-stayed bridge
Material	Steel
Spans	Large Span
Type	Steel Truss Bridge
Usage	Permanent Bridge
Length / Width	Customized

Bridge Description

The cable-stayed bridge, also known as diagonal bridge, features a structural system composed of a pressurized tower, strained cables, and a bent beam body. This design efficiently transfers loads through cables anchored between the main beam and cable tower.

Key Structural Components

Main Beam: Typically concrete, steel-concrete combination, or steel structure
Cable Tower: Primarily concrete structures, sometimes steel-concrete or steel
Stay Cable: Constructed from high-strength steel wire or steel strand

Span Configurations

Twin Tower Three Span: Ideal for crossing larger rivers with substantial main spans

Single Tower Double Span: Suitable for small to medium rivers and urban channels

Multi-Tower Configurations: Three-tower four-span and multi-tower designs for specialized applications

Cable Tower Design Variations

Cable towers are designed for both structural efficiency and aesthetic appeal, with several configuration options:

Cable Arrangement Systems

Three primary cable plane positions optimize performance for different applications:

Structural Advantages

Exceptional spanning capability for long distances
Reduced beam height (typically 1/50-1/200 of span length)
Efficient load distribution through cable system
Flexible construction methods including cantilever assembly
Adaptable to various materials including steel, concrete, and composites

Application Scenarios

Highway and road crossings
Pedestrian and bicycle bridges
High-speed rail infrastructure
Disaster-resistant bridge designs

Technical Specifications

Bridge Types	Bailey bridge, Modular bridge, Truss Bridge, Warren bridge, Arch bridge, Plate bridge, Beam bridge, Box girder bridge, Suspension bridge, Cable-stayed bridge, Floating bridge
Design Spans	10M to 300M single span
Carriage Way	Single lane, Double lanes, Multilane, Walkway
Loading Capacity	AASHTO HL93.HS15-44, HS20-44, HS25-44, BS5400 HA+20HB, HA+30HB, AS5100 Truck-T44, IRC 70R Class A/B, NATO STANAG MLC80/MLC110, Truck-60T, Trailer-80/100Ton
Steel Grade	EN10025 S355JR S355J0/EN10219 S460J0/EN10113 S460N/BS4360 Grade 55C, AS/NZS3678/3679/1163/Grade 350, ASTM A572/A572M GR50/GR65, GB1591 GB355B/C/D/460C
Certifications	ISO9001, ISO14001, ISO45001, EN1090, CIDB, COC, PVOC, SONCAP
