Customized Steel Cable Suspended Bridge With Hot Dip Galvanized Surface

Name: Customized Steel Cable Suspended Bridge With Hot Dip Galvanized Surface
Brand: EVERCROSS BRIDGE TECHNOLOGY (SHANGHAI) CO.,LTD.
SKU: COMPACT-200; COMPACT-100; CHINA 321 ; PB 100; LSB; GWD; DELTA; 450,etc
Price: 1,500.00 USD
Availability: InStock

Brand Name:	EVERCROSS
Model Number:	COMPACT-200; COMPACT-100; CHINA 321 ; PB 100; LSB; GWD; DELTA; 450,etc
MOQ:	negotiation
Price:	1000USD ~ 2000USD Per ton
Delivery Time:	negotiation
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CNAS; COC; PVOC; SONCAP; CIDB;FORM E;FORM L; FORM M, etc

Product Name:

Cable-stayed Bridge

Material:

Steel

Spans:

Large Span

Type:

Steel Truss Bridge

Usage:

Permanent Bridge

Length / Width:

Customized

Packaging Details:

According to detailed order

Highlight:

cable suspended bridge Galvanized

Customized Steel Cable Suspended Bridge

Product Description

Customized Steel Cable Suspended Bridge With Hot Dip Galvanized Surface

Product Name	Cable-stayed bridge
Material	Steel
Spans	Large Span
Type	Steel Truss Bridge
Usage	Permanent Bridge
Length / Width	Customized

Cable-stayed bridges, also known as diagonal bridges, feature a structural system where the main beam is directly supported by multiple cables anchored to bridge towers. This design consists of three primary components: the main beam, cable tower, and stay cables.

The load transfer mechanism efficiently distributes weight from the main beam through the cables to the tower and foundation. This design significantly reduces bending moments in the beam, allowing for smaller beam dimensions (typically 1/50 to 1/200 of the span) while increasing load capacity.

Span Layout Configurations

1. Twin Tower Three Span

Ideal for crossing large rivers due to its substantial main span capacity.

2. Single Tower Double Span

Suitable for medium-sized rivers and urban channels with smaller main spans.

3. Multi-Tower Designs

Three-tower four-span and multi-tower configurations increase structural flexibility but require careful engineering to manage deformation.

4. Auxiliary Piers & Lead Spans

These features improve structural performance by reducing stress amplitudes, increasing stiffness, and facilitating safer cantilever construction methods.

Structural Components

Main Beam

The beam distributes loads to cables while providing axial compression resistance. Material options include:

Prestressed concrete (spans <400m)
Steel-concrete composite (400-600m)
All steel construction (>600m)
Hybrid designs combining materials

Cable Tower Design

Tower configurations balance aesthetics and structural requirements, with common forms including:

Single column (simple structure)
A-frame (increased stiffness)
Inverted Y (reduces beam bending)

Stay Cable Systems

Two primary cable installation methods:

Parallel wire cables with cold-cast anchors
Parallel wire cables with clip anchors

Key Advantages

Superior structural efficiency through optimized load distribution
Construction flexibility with multiple erection methods
Enhanced resilience against wind, seismic activity, and natural forces
Reduced material requirements compared to conventional designs
Aesthetic appeal combined with functional performance

Evercross Steel Bridges Specifications

Bridge Types	Bailey bridge, Modular bridge, Truss Bridge, Warren bridge, Arch bridge, Plate bridge, Beam bridge, Box girder bridge, Suspension bridge, Cable-stayed bridge, Floating bridge
Design Spans	10M to 300M Single span
Carriage Way	SINGLE LANE, DOUBLE LANES, MULTILANE, WALKWAY
Loading Capacity	AASHTO HL93.HS15-44, HS20-44, HS25-44, BS5400 HA+20HB, HA+30HB, AS5100 Truck-T44, IRC 70R Class A/B, NATO STANAG MLC80/MLC110, Truck-60T, Trailer-80/100Ton
Steel Grade	EN10025 S355JR S355J0/EN10219 S460J0/EN10113 S460N/BS4360 Grade 55C, AS/NZS3678/3679/1163 Grade 350, ASTM A572/A572M GR50/GR65, GB1591 GB355B/C/D/460C
Certificates	ISO9001, ISO14001, ISO45001, EN1090, CIDB, COC, PVOC, SONCAP
