Highway Galvanization Composite Beam Bridge Plate Girder Bridge Long Span

Name: Highway Galvanization Composite Beam Bridge Plate Girder Bridge Long Span
Brand: EVERCROSS BRIDGE TECHNOLOGY (SHANGHAI) CO.,LTD.
SKU: COMPACT-200; COMPACT-100; CHINA 321 ; PB 100; LSB; GWD; DELTA; 450,etc
Price: 1,500.00 USD
Availability: InStock

Brand Name:	EVERCROSS
Model Number:	COMPACT-200; COMPACT-100; CHINA 321 ; PB 100; LSB; GWD; DELTA; 450,etc
MOQ:	negotiation
Price:	1000USD ~ 2000USD Per ton
Delivery Time:	negotiation
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CNAS; COC; PVOC; SONCAP; CIDB;FORM E;FORM L; FORM M, etc

Product Name:

Composite Beam Bridge

Bridge Deck:

Concrete

Material:

Prefabricated Steel

Spans:

Small Spans, Medium Spans, Large Spans

Durability:

Long-lasting

Installation:

Easy And Efficient Installation Process

Packaging Details:

According to detailed order

Highlight:

Galvanization Composite Beam Bridge

Long Span Composite Beam Bridge

Plate Girder Bridge Long Span

Product Description

Highway Galvanization Composite Beam Bridge Plate Girder Bridge Long Span

Product Specifications

Attribute	Value
Product Name	Composite beam bridge
Bridge Deck	Concrete
Material	Prefabricated Steel
Spans	Small Spans, Medium Spans, Large Spans
Durability	Long-lasting
Installation	Easy and efficient installation process

Product Description

The composite beam bridge is a composite structural bridge that combines steel members (such as steel plate beams, steel box beams, or steel truss beams) with reinforced concrete members working together through shear connectors. This innovative design separates the beam rib from the bridge panel through longitudinal horizontal joints, creating a combined section that offers superior performance.

Stress comparison between prefabricated T-beam and composite beam

Structural Types

Composite Plate Girder Bridge: Uses I-section steel beams for medium/small spans, reducing production costs
Composite Box Girder Bridge: Offers higher torsional rigidity and stability than I-section bridges
Composite Truss Bridge: Uses steel truss instead of solid beams for better permeability and aesthetics
Composite Rigid Frame Bridge: Consolidated with concrete piers for improved seismic performance

Composite box girder bridge structure

Key Features

Flexible shear transfer system with reliable connectors
Combined section increases stiffness while reducing steel quantity
Lower noise levels compared to all-steel bridges
Easy adjustment for slope and superelevation requirements
Reduced dead load compared to concrete bridges

Shear key connector designs

Advantages

Convenient construction due to steel strength and light weight
Reduced dead load benefits long-span bridge designs
Optimized material performance (steel in tension, concrete in compression)
Cost-effective solution for long-span applications
Durable design with long service life
Flexible design accommodates various bridge configurations

Applications

Composite beam bridges are widely used in highway and railway bridge construction, as well as for rehabilitation and replacement of aging structures. Their lightweight yet durable nature makes them ideal for projects requiring minimal traffic disruption.

Evercross Steel Bridges Overview

Product Range	Bailey bridge (Compact-200, Compact-100, LSB, PB100, China-321, BSB) Modular bridge (GWD, Delta, 450-type, etc.) Truss Bridge, Warren bridge, Arch bridge Plate bridge, Beam bridge, Box girder bridge Suspension bridge, Cable-stayed bridge, Floating bridge
Design Spans	10M to 300M Single span
Carriage Way	SINGLE LANE, DOUBLE LANES, MULTILANE, WALKWAY
Loading Capacity	AASHTO HL93.HS15-44, HS20-44, HS25-44 BS5400 HA+20HB, HA+30HB AS5100 Truck-T44 IRC 70R Class A/B NATO STANAG MLC80/MLC110 Truck-60T, Trailer-80/100Ton
Steel Grade	EN10025 S355JR S355J0/EN10219 S460J0/EN10113 S460N/BS4360 Grade 55C AS/NZS3678/3679/1163/Grade 350 ASTM A572/A572M GR50/GR65 GB1591 GB355B/C/D/460C
Certificates	ISO9001, ISO14001, ISO45001, EN1090, CIDB, COC, PVOC, SONCAP

Completed composite beam bridge project
