Sustainable Steel Arch Bridge Highway Truss Steel Bridge Economical

Name: Sustainable Steel Arch Bridge Highway Truss Steel Bridge Economical
Brand: EVERCROSS BRIDGE TECHNOLOGY (SHANGHAI) CO.,LTD.
SKU: COMPACT-200; COMPACT-100; CHINA 321 ; PB 100; LSB; GWD; DELTA; 450,etc
Price: 1,500.00 USD
Availability: InStock

Brand Name:	EVERCROSS
Model Number:	COMPACT-200; COMPACT-100; CHINA 321 ; PB 100; LSB; GWD; DELTA; 450,etc
MOQ:	negotiation
Price:	1000USD ~ 2000USD Per ton
Delivery Time:	negotiation
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CNAS; COC; PVOC; SONCAP; CIDB;FORM E;FORM L; FORM M, etc

Product Name:

Steel Arch Bridge

Bridge Deck:

Concrete Deck

Type:

Upper Bearing Type, Middle Bearing Type, Lower Bearing Type

Material:

Prefabricated Steel

Surface Finish:

Shot Blasting ,painted

Application:

Highway, Railway, Pedestrian Bridge

Packaging Details:

According to detailed order

Highlight:

Sustainable Steel Arch Bridge

Highway Truss Steel Bridge

Sustainable Truss Steel Bridge

Product Description

Sustainable Steel Arch Bridge Highway Truss Steel Bridge Economical

Product Name	Steel Arch Bridge
Bridge Deck	Concrete Deck
Type	Upper bearing type, Middle bearing type, Lower bearing type
Material	Prefabricated Steel
Surface Finish	Shot blasting, painted
Application	Highway, Railway, Pedestrian Bridge

Main Structural Form of Steel Arch Bridge

Steel arch bridges employ an arch structure made primarily of steel, designed to bear weight and forces from traffic while distributing them evenly to supports at each end. Steel's high recyclability makes these bridges environmentally friendly and sustainable.

Structural Classification

Section form: Steel box arch, steel pipe arch, steel truss arch
Space posture: Parallel arch ribs, basket arch ribs, butterfly arch ribs
Carriageway position: Upper bearing type, middle bearing type, lower bearing type
Boom layout: Parallel vertical boom, inclined boom, mesh boom

Structural System Classification

Steel arch bridges include both composite system and simple system designs. Composite systems combine the arch with other structural elements, while simple systems rely solely on the arch ring as the main force component.

Main Arch Structure

Steel arches can be designed as truss arches, box arches, or plate arches. Truss arch bridges are particularly important for large spans, with design considerations including:

Arch rib truss layout
Arch axis configuration
Vector span ratio
Vault and arch foot height selection
Boundary conditions
Bar section form and area

Steel arch bridges are renowned for their exceptional strength, durability, and aesthetic appeal. The arch shape provides excellent load-bearing capabilities by efficiently transferring weight to supports.

Key Structural Components

Arch Rib

The primary load-bearing member that mainly withstands axial pressure. Available in box, pipe, and truss types, with trussed arches offering light weight, greater span capacity, and good economy.

Boom

Transfers deck load to the arch rib. Available as rigid (steel pipe/section) or flexible (high-strength steel wire) configurations, with various elevation arrangements including parallel vertical, inclined, and mesh booms.

Tie Bar (Beam)

Bears the thrust of non-thrust arches, available in rigid and flexible configurations to withstand significant axial tension.

Cross Brace

Ensures transverse stiffness and stability, with common configurations including one-word, K-shaped, X-shaped, and meter-shaped braces positioned according to structural requirements.

Design Parameters

Key considerations include rise span ratio (typically 1/4~1/5), arch axis form (arc line, quadratic parabola, catenary), and vault/arch foot height selection (equal or variable height).

Advantages of Steel Arch Bridges

Strength & Durability: High-strength material withstands heavy loads and harsh conditions
Constructability: Suitable for prefabrication and modular construction methods
Recyclability: Environmentally friendly with high material recyclability
Aesthetic Appeal: Attractive architectural form with clean lines

Applications

Road bridges requiring long spans
Pedestrian bridges in urban areas
Highway overpasses crossing other infrastructure
Railway bridges requiring durable structures

Evercross Steel Bridges Overview

Product Range	Bailey bridge, Modular bridge, Truss Bridge, Warren bridge, Arch bridge, Plate bridge, Beam bridge, Box girder bridge, Suspension bridge, Cable-stayed bridge, Floating bridge
Design Spans	10M TO 300M Single span
Carriage Way	SINGLE LANE, DOUBLE LANES, MULTILANE, WALKWAY
Loading Capacity	AASHTO HL93.HS15-44, HS20-44, HS25-44, BS5400 HA+20HB, HA+30HB, AS5100 Truck-T44, IRC 70R Class A/B, NATO STANAG MLC80/MLC110, Truck-60T, Trailer-80/100Ton
Steel Grade	EN10025 S355JR S355J0/EN10219 S460J0/EN10113 S460N/BS4360 Grade 55C, AS/NZS3678/3679/1163/Grade 350, ASTM A572/A572M GR50/GR65, GB1591 GB355B/C/D/460C
Certificates	ISO9001, ISO14001, ISO45001, EN1090, CIDB, COC, PVOC, SONCAP
