Q460 Q335 Steel Box Girder Bridge Heavy Loading Capacity Long Lifespan

Name: Q460 Q335 Steel Box Girder Bridge Heavy Loading Capacity Long Lifespan
Brand: EVERCROSS BRIDGE TECHNOLOGY (SHANGHAI) CO.,LTD.
SKU: COMPACT-200; COMPACT-100; CHINA 321 ; PB 100; LSB; GWD; DELTA; 450,etc
Price: 1,500.00 USD
Availability: InStock

Brand Name:	EVERCROSS
Model Number:	COMPACT-200; COMPACT-100; CHINA 321 ; PB 100; LSB; GWD; DELTA; 450,etc
MOQ:	negotiation
Price:	1000USD ~ 2000USD Per ton
Delivery Time:	negotiation
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CNAS; COC; PVOC; SONCAP; CIDB;FORM E;FORM L; FORM M, etc

Product Name:

Steel Box-girder Bridge

Bridge Deck:

Concrete

Type:

Girder Bridge

Material:

Prefabricated Steel

Grade:

Q460, Q335

Wind Resistance:

Class12

Cost:

High

Standard:

AISI, ASTM, BS, DIN, GB, JIS

Installation Time:

6months

Construction Time:

Short

Dimensions:

Customized

Feature:

Large Span

Lifespan:

100years

Width:

10m

Seismic Resistance:

Anti

Packaging Details:

According to detailed order

Highlight:

Q335 Steel Box Girder Bridge

Q460 Steel Box Girder Bridge

Heavy Loading steel tub girder bridge

Product Description

Q460 Q335 Steel Box Girder Bridge

Heavy Loading Capacity with Long Lifespan

Product Specifications

Attribute	Value
Product Name	Steel Box-girder bridge
Bridge Deck	Concrete
Type	Girder Bridge
Material	Prefabricated Steel
Grade	Q460, Q335
Wind Resistance	Class12
Standard	AISI, ASTM, BS, DIN, GB, JIS
Installation Time	6 months
Dimensions	Customized
Feature	Large Span
Lifespan	100 years
Width	10m
Seismic Resistance	Anti-seismic

Structural Overview

The steel box-girder bridge features exceptional flexural and torsional stiffness with significant loading capacity. Composed of top plate (bridge panel), beam web, bottom plate, longitudinal stiffener, transverse stiffener, and diaphragm plate (cross beam), it offers superior structural integrity.

Key Construction Features

Factory welding is prioritized to ensure weld quality, with strict quality control measures. The top plate's lower edge incorporates vertical and horizontal stiffeners forming an orthogonal bridge panel, optimizing mechanical properties in both bridge directions while conserving steel.

Structural Variations

Single Box Design: Ideal for smaller bridge widths (3 lanes) with beam spacing of 1.5m-3m (open rib) or 2m-4m (closed rib).

Double Box Design: Recommended for wider bridges where single box dimensions become impractical for production, transportation, or installation.

Multi-box Design: Optimal for applications with small spans and large bridge widths, featuring uniformly-spaced main beams for balanced load distribution.

Structural Components

Longitudinal Beam

Reduces span of reinforced concrete bridge panels when main beam spacing is large, while improving steel bridge panel stiffness. Spacing typically limited to 3m for concrete panels.

Support Systems

Multi-box designs utilize one support per steel box. Temporary fulcrum supports with jacks are implemented for structural reinforcement during installation.

Mechanical Characteristics

Engineered to withstand bending moments and concentrated forces, with structural measures including:

Transverse partitions to prevent distortion and lateral bending
Stiffening ribs to maintain compression flange stability
Reinforcement for tension flange during fabrication and installation
Web stiffening to prevent buckling under stress

Applications & Advantages

Applications: Road, rail, and high-speed rail infrastructure projects requiring durable, long-span solutions.

Key Benefits

Large flange width provides exceptional bending resistance
Superior torsional stiffness for curved bridge applications
Lightweight construction with significant steel savings
High flexural and torsional stiffness
Rapid installation with simplified maintenance
Continuous beam formation capability
Modern, aesthetically pleasing design

Evercross Steel Bridges Specifications

Category	Specifications
Bridge Types	Bailey bridge, Modular bridge, Truss Bridge, Warren bridge, Arch bridge, Plate bridge, Beam bridge, Box girder bridge, Suspension bridge, Cable-stayed bridge, Floating bridge
Design Spans	10M TO 300M Single span
Carriage Way	SINGLE LANE, DOUBLE LANES, MULTILANE, WALKWAY
Loading Capacity	AASHTO HL93.HS15-44, HS20-44, HS25-44, BS5400 HA+20HB, HA+30HB, AS5100 Truck-T44, IRC 70R Class A/B, NATO STANAG MLC80/MLC110, Truck-60T, Trailer-80/100Ton
Steel Grade	EN10025 S355JR S355J0/EN10219 S460J0/EN10113 S460N/BS4360 Grade 55C, AS/NZS3678/3679/1163/Grade 350, ASTM A572/A572M GR50/GR65, GB1591 GB355B/C/D/460C
Certificates	ISO9001, ISO14001, ISO45001, EN1090, CIDB, COC, PVOC, SONCAP
Welding Standards	AWS D1.1/AWS D1.5, AS/NZS 1554 or equivalent
Bolting Standards	ISO898, AS/NZS1252, BS3692 or equivalent
Galvanization Codes	ISO1461, AS/NZS 4680, ASTM-A123, BS1706 or equivalent
