Prefabricated Steel Truss Bridge
Created with Pixso. GB Q355B Large Span Steel Truss Bridge For Railway WIth Long Life

GB Q355B Large Span Steel Truss Bridge For Railway WIth Long Life

Brand Name: EVERCROSS
Model Number: COMPACT-200; COMPACT-100; CHINA 321 ; PB 100; LSB; GWD; DELTA; 450,etc
MOQ: negotiation
Price: 1000USD ~ 2000USD Per ton
Delivery Time: negotiation
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Detail Information
Place of Origin:
China
Certification:
CNAS; COC; PVOC; SONCAP; CIDB;FORM E;FORM L; FORM M, etc
Product Name:
Steel Truss Bridge
Material:
Prefabricate Steel
Spans:
Short And Medium Spans
Bridge Deck:
Composite Deck
Surface Protection:
Painted
Standard:
AISI, ASTM, BS, DIN, GB, JIS
Surface Finish:
Painted Or Galvanized
Size:
Customized Size
Packaging Details:
According to detailed order
Highlight:

Q355B Steel Truss Bridge

,

Large Span Steel Truss Bridge

,

Long Life metal truss bridge

Product Description
GB Q355B Large Span Steel Truss Bridge For Railway With Long Life
Product Specifications
Attribute Value
Product Name Steel Truss Bridge
Material Prefabricate Steel
Spans Short And Medium Spans
Bridge Deck Composite Deck
Surface Protection Painted
Standard AISI, ASTM, BS, DIN, GB, JIS
Surface Finish Painted or Galvanized
Size Customized Size
Product Overview

The steel truss bridge utilizes a framework of steel trusses to support the bridge deck, consisting of interconnected bars or beams arranged in a triangular pattern for excellent strength and stiffness. These bridges are renowned for their durability, versatility, and rapid installation capabilities.

GB Q355B Large Span Steel Truss Bridge For Railway WIth Long Life 0
Structural Components
Main Girder

The primary load-bearing structure composed of upper chord, lower chord, and belly rod (including diagonal and vertical bars). Nodes are categorized into large and small nodes with defined pitch distances.

Bracing

Classified into longitudinal and horizontal connections that stabilize the structure against lateral loads. The system includes upper and lower horizontal longitudinal connections to withstand transverse forces and reduce chord free length.

Bridge Deck System

Comprising longitudinal beams, transverse beams, and their connections. Load distribution flows from longitudinal beams to transverse beams, then to the main truss.

Bridge Floor

The walking surface for vehicles and pedestrians, designed similarly to steel beam and combined beam bridges.

Truss Types
Triangular Truss

Simple structure with fixed design, facilitating easy installation and manufacturing.

GB Q355B Large Span Steel Truss Bridge For Railway WIth Long Life 1
Diagonal Bar Truss

Features multiple bar specifications with significant vertical rod internal forces and large nodes.

GB Q355B Large Span Steel Truss Bridge For Railway WIth Long Life 2
K-Shaped Truss

Distributes shear force across two diagonal rods, creating shorter sections ideal for mounting/dismounting bridges in small to medium spans.

GB Q355B Large Span Steel Truss Bridge For Railway WIth Long Life 3
Double-Vented Bar Truss

Optimized for large spans with short compression rods that enhance buckling stability and simplify joint plate arrangements.

GB Q355B Large Span Steel Truss Bridge For Railway WIth Long Life 4
Key Characteristics
  • Structural Appearance: Distinctive lattice-like framework of triangular steel units
  • Material Properties: High-strength steel with excellent tensile/compressive strength and ductility
  • Modular Construction: Factory-fabricated components for quality control and rapid assembly
  • High Strength-to-Weight Ratio: Capable of long spans while remaining relatively lightweight
Technical Specifications
Category Specifications
Bridge Types Bailey bridge, Modular bridge, Truss Bridge, Warren bridge, Arch bridge, Plate bridge, etc.
Design Spans 10M to 300M Single span
Carriage Way Single lane, Double lanes, Multilane, Walkway
Loading Capacity AASHTO HL93, BS5400 HA+20HB, AS5100 Truck-T44, IRC 70R Class A/B, NATO STANAG MLC80/110
Steel Grade EN10025 S355JR, ASTM A572 GR50/65, GB1591 GB355B/C/D/460C
Certifications ISO9001, ISO14001, ISO45001, EN1090, CIDB, COC
Applications
  • Highway and road bridges across various span lengths
  • Pedestrian bridges
  • Railway crossings
  • Temporary and permanent infrastructure solutions
GB Q355B Large Span Steel Truss Bridge For Railway WIth Long Life 5
