Prefabricated Structural Steel Composite Truss Bridge Customized Size

Name: Prefabricated Structural Steel Composite Truss Bridge Customized Size
Brand: EVERCROSS BRIDGE TECHNOLOGY (SHANGHAI) CO.,LTD.
SKU: COMPACT-200; COMPACT-100; CHINA 321 ; PB 100; LSB; GWD; DELTA; 450,etc
Price: 1,500.00 USD
Availability: InStock

Brand Name:	EVERCROSS
Model Number:	COMPACT-200; COMPACT-100; CHINA 321 ; PB 100; LSB; GWD; DELTA; 450,etc
MOQ:	negotiation
Price:	1000USD ~ 2000USD Per ton
Delivery Time:	negotiation
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CNAS; COC; PVOC; SONCAP; CIDB;FORM E;FORM L; FORM M, etc

Product Name:

Composite Beam Bridge

Bridge Deck:

Concrete

Material:

Prefabricated Steel

Spans:

Small Spans, Medium Spans, Large Spans

Durability:

Long-lasting

Installation:

Easy And Efficient Installation Process

Packaging Details:

According to detailed order

Highlight:

composite truss bridge Customized size

Prefabricated Steel composite truss bridge

Structural Steel composite truss bridge

Product Description

Prefabricated Structural Steel Composite Truss Bridge

Product Specifications

Attribute	Value
Product Name	Composite beam bridge
Bridge Deck	Concrete
Material	Prefabricated Steel
Spans	Small Spans, Medium Spans, Large Spans
Durability	Long-lasting
Installation	Easy and efficient installation process

Composite Beam Bridge Description

A composite structural beam bridge combines steel members (steel plate beams, steel box beams, steel truss beams) with reinforced concrete members working together through shear connectors. While simply-supported beam bridges were traditionally most common, modern applications now include continuous beam bridges, cable-stayed bridges, suspension bridges, and tied arch bridges.

Stress comparison between prefabricated T-beam and composite beam

Structural Characteristics

Combination section design increases stiffness while reducing steel quantity
Lower noise levels compared to all-steel bridges under live loads
Easy slope and superelevation adjustment capabilities
Utilizes short section steel components (channel steel, angle steel)
Flexible shear transfer through diagonal reinforcement or capped bolts

Structural Forms

Composite Plate Girder Bridge: Uses I-section steel beams for medium/small spans, reducing production costs while maintaining structural integrity.

Composite Box Girder Bridge: Offers higher torsional rigidity and stability than I-section designs, with improved steel box girder stability through concrete pouring.

Composite Truss Bridge: Replaces solid steel beams with steel trusses for better permeability and aesthetics, though requiring more complex joint designs.

Key Advantages

Structural Efficiency: Optimizes material use with steel in tension and concrete in compression
Reduced Dead Load: Lighter than concrete bridges, especially beneficial for long spans
Cost Effective: Lower material requirements and faster construction times
Durable Construction: Concrete protects steel from corrosion while steel provides strength
Design Flexibility: Adaptable to various bridge configurations and load requirements

Evercross Steel Bridges Overview

Bridge Types	Bailey bridge (Compact-200, Compact-100, LSB, PB100), Modular bridge (GWD, Delta), Truss Bridge, Warren bridge, Arch bridge, Plate bridge, Beam bridge, Box girder bridge, Suspension bridge, Cable-stayed bridge, Floating bridge
Design Spans	10M to 300M Single span
Carriage Way	SINGLE LANE, DOUBLE LANES, MULTILANE, WALKWAY
Loading Capacity	AASHTO HL93.HS15-44, HS20-44, HS25-44, BS5400 HA+20HB, HA+30HB, AS5100 Truck-T44, IRC 70R Class A/B, NATO STANAG MLC80/MLC110, Truck-60T, Trailer-80/100Ton
Steel Grade	EN10025 S355JR S355J0/EN10219 S460J0/EN10113 S460N/BS4360 Grade 55C, AS/NZS3678/3679/1163/Grade 350, ASTM A572/A572M GR50/GR65, GB1591 GB355B/C/D/460C
Certificates	ISO9001, ISO14001, ISO45001, EN1090, CIDB, COC, PVOC, SONCAP
