Concrete Deck Composite Steel Bridge Customizable Small Spans

Name: Concrete Deck Composite Steel Bridge Customizable Small Spans
Brand: EVERCROSS BRIDGE TECHNOLOGY (SHANGHAI) CO.,LTD.
SKU: COMPACT-200; COMPACT-100; CHINA 321 ; PB 100; LSB; GWD; DELTA; 450,etc
Price: 1,500.00 USD
Availability: InStock

Brand Name:	EVERCROSS
Model Number:	COMPACT-200; COMPACT-100; CHINA 321 ; PB 100; LSB; GWD; DELTA; 450,etc
MOQ:	negotiation
Price:	1000USD ~ 2000USD Per ton
Delivery Time:	negotiation
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CNAS; COC; PVOC; SONCAP; CIDB;FORM E;FORM L; FORM M, etc

Product Name:

Composite Beam Bridge

Bridge Deck:

Concrete

Material:

Prefabricated Steel

Spans:

Small Spans, Medium Spans, Large Spans

Durability:

Long-lasting

Installation:

Easy And Efficient Installation Process

Packaging Details:

According to detailed order

Highlight:

Concrete Deck Composite Steel Bridge

Composite Steel Bridge Customizable

Small Spans composite truss bridge

Product Description

Composite Beam Bridge - Concrete Deck Steel Structure

Key Features

Combines steel members with reinforced concrete for superior structural performance
Available in small, medium, and large span configurations
Long-lasting durability with easy and efficient installation
Prefabricated steel components reduce construction time

Product Specifications

Attribute	Value
Product Name	Composite beam bridge
Bridge Deck	Concrete
Material	Prefabricated Steel
Spans	Small Spans, Medium Spans, Large Spans
Durability	Long-lasting
Installation	Easy and efficient installation process

Structural Overview

Composite beam bridges combine steel members (plate beams, box beams, truss beams) with reinforced concrete components through shear connectors. This innovative design allows for staged construction where steel beams are erected first, followed by prefabricated panels and cast-in-place concrete to create a unified structure.

Types of Composite Beams

Concrete Composite Beams: Integrated through cast-in-place concrete in joints or with precast slabs.

Steel-Concrete Composite Beams: Feature steel beam ribs with reinforced concrete slabs connected via shear keys.

Structural Characteristics

Combined section design increases stiffness while reducing steel quantity
Reduced noise compared to all-steel bridges under live load
Easy adjustment of slope and superelevation
Requires reliable shear transfer devices between steel and concrete components

Bridge Types

Composite Plate Girder Bridge: Uses I-section steel beams for cost-effective medium/small span solutions.

Composite Box Girder Bridge: Offers higher torsional rigidity and stability with steel box girders.

Composite Truss Bridge: Combines steel trusses with concrete panels for enhanced aesthetics and permeability.

Composite Rigid Frame Bridge: Integrates steel-concrete beams with piers for seismic resistance and large headroom.

Technical Advantages

Reduced dead load compared to concrete bridges
Optimized material usage (steel for tension, concrete for compression)
Cost-effective for long-span applications
Improved structural stiffness and stability
Reduced noise pollution versus all-steel bridges

Evercross Steel Bridges Specifications

Category	Specifications
Bridge Types	Bailey bridge, Modular bridge, Truss Bridge, Warren bridge, Arch bridge, Plate bridge, Beam bridge, Box girder bridge, Suspension bridge, Cable-stayed bridge, Floating bridge
Design Spans	10M TO 300M Single span
Carriage Way	SINGLE LANE, DOUBLE LANES, MULTILANE, WALKWAY
Loading Capacity	AASHTO HL93.HS15-44, HS20-44, HS25-44, BS5400 HA+20HB, HA+30HB, AS5100 Truck-T44, IRC 70R Class A/B, NATO STANAG MLC80/MLC110
Steel Grade	EN10025 S355JR S355J0/EN10219 S460J0/EN10113 S460N/BS4360 Grade 55C, AS/NZS3678/3679/1163/Grade 350, ASTM A572/A572M GR50/GR65, GB1591 GB355B/C/D/460C
Certificates	ISO9001, ISO14001, ISO45001, EN1090, CIDB, COC, PVOC, SONCAP
