Rigid Frame Composite Steel Bridge Medium Spans Scaffold Construction

Brand Name:	EVERCROSS
Model Number:	COMPACT-200; COMPACT-100; CHINA 321 ; PB 100; LSB; GWD; DELTA; 450,etc
MOQ:	negotiation
Price:	1000USD ~ 2000USD Per ton
Delivery Time:	negotiation
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CNAS; COC; PVOC; SONCAP; CIDB;FORM E;FORM L; FORM M, etc

Product Name:

Composite Beam Bridge

Bridge Deck:

Concrete

Material:

Prefabricated Steel

Spans:

Small Spans, Medium Spans, Large Spans

Durability:

Long-lasting

Installation:

Easy And Efficient Installation Process

Packaging Details:

According to detailed order

Highlight:

Rigid Frame Composite Steel Bridge

Composite Steel Bridge Medium Span

Scaffold construction composite truss bridge

Product Description

Rigid Frame Composite Steel Bridge Medium Spans Scaffold Construction

Attribute	Value
Product Name	Composite beam bridge
Bridge Deck	Concrete
Material	Prefabricated Steel
Spans	Small Spans, Medium Spans, Large Spans
Durability	Long-lasting
Installation	Easy and efficient installation process

Composite Beam Bridge Description

The composite beam bridge combines steel members (steel plate beams, steel box beams, steel truss beams) with reinforced concrete members through shear connectors to create a unified structural system. This assembled bridge span structure separates the beam rib from the bridge panel via longitudinal horizontal joints, resulting in staged stress distribution.

Composite beams are categorized into concrete composite beams and steel-concrete composite beams based on materials used. Steel-concrete composite beams feature steel beam ribs and reinforced concrete bridge panels connected via shear keys.

Structural Characteristics

Combined section design increases stiffness while reducing steel quantity
Lower noise levels under live load compared to all-steel bridges
Easy slope and superelevation adjustment
Utilizes short section steel components (channel steel, angle steel)
Flexible shear transfer system with diagonal reinforcement options

Structural Forms

Composite Plate Girder Bridge: Ideal for medium and small spans, utilizing I-section steel beams (rolled or welded) to reduce production costs. Often features asymmetric steel beam sections.

Composite Box Girder Bridge: Offers higher torsional rigidity and stability than I-section bridges. Enables increased crossing capacity and solves clearance issues without traffic interruption.

Composite Rigid Frame Bridge: Features steel-concrete composite beams consolidated with concrete piers, offering large headroom, seismic resistance, and eliminating falling beam risks.

Key Advantages

Simplified construction process due to steel's strength and lightweight properties
Reduced dead load compared to concrete bridges, especially beneficial for long spans
Optimized material performance with steel handling tension and concrete compression
Cost-effective solution, particularly for long-span applications

Applications

Composite beam bridges serve in highway and railway infrastructure, industrial/commercial developments (ports, industrial complexes), and for rehabilitation/replacement of aging bridges. They provide durable solutions with minimal traffic disruption.

Evercross Steel Bridges Specifications

Bridge Types: Bailey bridge, Modular bridge, Truss Bridge, Warren bridge, Arch bridge, Plate bridge, Beam bridge, Box girder bridge, Suspension bridge, Cable-stayed bridge, Floating bridge

Design Spans: 10M to 300M single span

Carriage Way: Single lane, Double lanes, Multilane, Walkway

Loading Capacity: Compliant with AASHTO, BS5400, AS5100, IRC, and NATO standards

Certifications: ISO9001, ISO14001, ISO45001, EN1090, CIDB, COC, PVOC, SONCAP
