High Tensile Strength Composite Truss Bridge Flexible And Easy To Set Up

Name: High Tensile Strength Composite Truss Bridge Flexible And Easy To Set Up
Brand: EVERCROSS BRIDGE TECHNOLOGY (SHANGHAI) CO.,LTD.
SKU: COMPACT-200; COMPACT-100; CHINA 321 ; PB 100; LSB; GWD; DELTA; 450,etc
Price: 1,500.00 USD
Availability: InStock

Brand Name:	EVERCROSS
Model Number:	COMPACT-200; COMPACT-100; CHINA 321 ; PB 100; LSB; GWD; DELTA; 450,etc
MOQ:	negotiation
Price:	1000USD ~ 2000USD Per ton
Delivery Time:	negotiation
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CNAS; COC; PVOC; SONCAP; CIDB;FORM E;FORM L; FORM M, etc

Product Name:

Composite Beam Bridge

Bridge Deck:

Concrete

Material:

Prefabricated Steel

Spans:

Small Spans, Medium Spans, Large Spans

Durability:

Long-lasting

Installation:

Easy And Efficient Installation Process

Packaging Details:

According to detailed order

Highlight:

high tensile strength Composite Truss Bridge

Flexible Composite Truss Bridge

Flexible Composite Steel Bridge

Product Description

High Tensile Strength Composite Truss Bridge

Flexible and Easy to Set Up

Attribute	Value
Product Name	Composite beam bridge
Bridge Deck	Concrete
Material	Prefabricated Steel
Spans	Small Spans, Medium Spans, Large Spans
Durability	Long-lasting
Installation	Easy and efficient installation process

A composite beam bridge combines steel members (such as steel plate beams, steel box beams, or steel truss beams) with reinforced concrete members through shear connectors to create a unified structural system. The steel section provides high tensile strength and stiffness, while the concrete slab offers excellent compressive strength and protects the steel from fire and corrosion.

Types of Composite Beam Bridges

Concrete Composite Beams: Integrated by casting concrete in situ in the joints or together with the precast slab of the bridge floor.

Steel-Concrete Composite Beams: Made of steel beams in the beam ribs and reinforced concrete slabs in the bridge panels, combined through shear keys (connectors).

Structural Characteristics

Reduced noise compared to all-steel bridges
Easy slope and superelevation adjustment
Combined section increases stiffness while reducing steel quantity
Requires reliable shear transfer devices between steel and concrete

Structural Forms

Composite Plate Girder Bridge: Uses I-section steel beams for medium and small spans, reducing production and installation costs.

Composite Box Girder Bridge: Offers higher torsional rigidity and stability than I-section bridges, with construction methods including cast-in-place and precast segmental.

Composite Truss Bridge: Uses steel truss instead of solid steel beam for better permeability and aesthetics, though with more complex joint designs.

Composite Rigid Frame Bridge: Consolidated with concrete piers for improved seismic performance and larger headroom under the bridge.

Key Advantages

Convenient construction due to steel's strength and light weight
Reduced dead load compared to concrete bridges
Optimal material performance with steel in tension and concrete in compression
Cost savings, especially in long-span bridges
Reduced steel quantity and painting costs
Improved stiffness, stability, and structural integrity

Bridge Panel Design

Reinforced concrete bridge panels bear longitudinal bending moments and cross-bridge internal forces. They can be cast-in-place or precast, with straight or curved bottom surfaces.

Shear Connectors

Critical for joint operation of steel and concrete, shear connectors withstand longitudinal shear forces and resist relative slip. Common types include welded nail shear keys, channel steel shear keys, and perforated plate connectors.

Evercross Steel Bridges Overview

Specification	Details
Bridge Types	Bailey bridge, Modular bridge, Truss Bridge, Warren bridge, Arch bridge, Plate bridge, Beam bridge, Box girder bridge, Suspension bridge, Cable-stayed bridge, Floating bridge
Design Spans	10M to 300M Single span
Carriage Way	Single lane, Double lanes, Multilane, Walkway
Loading Capacity	AASHTO HL93.HS15-44, HS20-44, HS25-44, BS5400 HA+20HB, HA+30HB, AS5100 Truck-T44, IRC 70R Class A/B, NATO STANAG MLC80/MLC110, Truck-60T, Trailer-80/100Ton
Steel Grade	EN10025 S355JR S355J0/EN10219 S460J0/EN10113 S460N/BS4360 Grade 55C, AS/NZS3678/3679/1163/Grade 350, ASTM A572/A572M GR50/GR65, GB1591 GB355B/C/D/460C
Certificates	ISO9001, ISO14001, ISO45001, EN1090, CIDB, COC, PVOC, SONCAP
Welding	AWS D1.1/AWS D1.5, AS/NZS 1554 or equivalent
Bolts	ISO898, AS/NZS1252, BS3692 or equivalent
Galvanization Code	ISO1461, AS/NZS 4680, ASTM-A123, BS1706 or equivalent
