Rigid Steel Concrete Composite Bridge For Railway Easy Assembled

Name: Rigid Steel Concrete Composite Bridge For Railway Easy Assembled
Brand: EVERCROSS BRIDGE TECHNOLOGY (SHANGHAI) CO.,LTD.
SKU: COMPACT-200; COMPACT-100; CHINA 321 ; PB 100; LSB; GWD; DELTA; 450,etc
Price: 1,500.00 USD
Availability: InStock

Brand Name:	EVERCROSS
Model Number:	COMPACT-200; COMPACT-100; CHINA 321 ; PB 100; LSB; GWD; DELTA; 450,etc
MOQ:	negotiation
Price:	1000USD ~ 2000USD Per ton
Delivery Time:	negotiation
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CNAS; COC; PVOC; SONCAP; CIDB;FORM E;FORM L; FORM M, etc

Product Name:

Composite Beam Bridge

Bridge Deck:

Concrete

Material:

Prefabricated Steel

Spans:

Small Spans, Medium Spans, Large Spans

Durability:

Long-lasting

Installation:

Easy And Efficient Installation Process

Packaging Details:

According to detailed order

Highlight:

Rigid Steel Concrete Composite Bridge

railway Steel Concrete Composite Bridge

Easy Assembled Composite Steel Bridge

Product Description

Rigid Steel Concrete Composite Bridge For Railway - Easy Assembled

Product Overview

The composite beam bridge combines steel members (plate beams, box beams, truss beams) with reinforced concrete components through shear connectors, creating a durable and efficient bridge solution suitable for railway and highway applications.

Key Specifications

Attribute	Value
Product Name	Composite beam bridge
Bridge Deck	Concrete
Material	Prefabricated Steel
Spans	Small Spans, Medium Spans, Large Spans
Durability	Long-lasting
Installation	Easy and efficient installation process

Structural Characteristics

Combination section design increases stiffness while reducing steel quantity
Lower noise levels compared to all-steel bridges under live load
Easy adjustment of slope and external superelevation
Reliable shear transfer mechanism between steel and concrete components

Types of Composite Beam Bridges

Composite Plate Girder Bridge

I-section steel beams for medium and small spans, reducing production and installation costs. Can use rolled section steel or welded steel beams with asymmetric sections.

Composite Box Girder Bridge

Higher torsional rigidity and stability than I-section bridges. Solves clearance issues and avoids traffic interruption during construction.

Composite Truss Bridge

Steel truss replaces solid steel beam, offering better permeability and aesthetics. Requires more complex joint design.

Composite Rigid Frame Bridge

Consolidated with concrete piers, providing large headroom, beautiful shape, and higher seismic performance than simple supported bridges.

Key Advantages

Convenient construction due to steel strength and light weight
Reduced dead load compared to concrete bridges
Optimized material performance (steel in tension, concrete in compression)
Cost savings, especially in long-span bridges
High strength-to-weight ratio
Durable and maintenance-friendly design

Applications

Ideal for both highway and railway bridges, offering versatile solutions for various infrastructure projects with spans ranging from 10M to 300M.

Evercross Steel Bridges Specifications

Category	Details
Bridge Types	Bailey bridge, Modular bridge, Truss Bridge, Warren bridge, Arch bridge, Plate bridge, Beam bridge, Box girder bridge, Suspension bridge, Cable-stayed bridge, Floating bridge
Design Spans	10M TO 300M Single span
Carriage Way	SINGLE LANE, DOUBLE LANES, MULTILANE, WALKWAY
Loading Capacity	AASHTO HL93.HS15-44, HS20-44, HS25-44, BS5400 HA+20HB, HA+30HB, AS5100 Truck-T44, IRC 70R Class A/B, NATO STANAG MLC80/MLC110
Steel Grade	Various international standards including EN10025, AS/NZS3678, ASTM A572, GB1591
Certifications	ISO9001, ISO14001, ISO45001, EN1090, CIDB, COC, PVOC, SONCAP
