OEM Pedestrian Truss Bridge With Painted Surface Protection Fast Construction

Name: OEM Pedestrian Truss Bridge With Painted Surface Protection Fast Construction
Brand: EVERCROSS BRIDGE TECHNOLOGY (SHANGHAI) CO.,LTD.
SKU: COMPACT-200; COMPACT-100; CHINA 321 ; PB 100; LSB; GWD; DELTA; 450,etc
Price: 1,500.00 USD
Availability: InStock

Brand Name:	EVERCROSS
Model Number:	COMPACT-200; COMPACT-100; CHINA 321 ; PB 100; LSB; GWD; DELTA; 450,etc
MOQ:	negotiation
Price:	1000USD ~ 2000USD Per ton
Delivery Time:	negotiation
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CNAS; COC; PVOC; SONCAP; CIDB;FORM E;FORM L; FORM M, etc

Product Name:

Steel Truss Bridge

Material:

Prefabricate Steel

Spans:

Short And Medium Spans

Bridge Deck:

Composite Deck

Surface Protection:

Painted

Standard:

AISI, ASTM, BS, DIN, GB, JIS

Surface Finish:

Painted Or Galvanized

Size:

Customized Size

Packaging Details:

According to detailed order

Highlight:

OEM Pedestrian Truss Bridge

Painted Surface Pedestrian Truss Bridge

Fast construction Pedestrian Truss Bridge

Product Description

OEM Pedestrian Truss Bridge With Painted Surface Protection Fast Construction

Product Name	Steel Truss Bridge
Material	Prefabricate Steel
Spans	Short And Medium Spans
Bridge Deck	Composite Deck
Surface Protection	Painted
Standard	AISI, ASTM, BS, DIN, GB, JIS
Surface Finish	Painted or Galvanized
Size	Customized Size

Steel Truss Bridge Description

The steel truss bridge is a structural system between beams and arches, combining a bent upper beam structure and pressure-bearing lower column into an integrated compression-bending and thrust structure.

Bridge Types

Based on bridge floor position:

Upper bearing steel truss bridge: Bridge floor located in the upper part of the main truss
Lower bearing steel truss bridge: Bridge floor located in the lower part of the main truss

Structural Components

Main Girder: Primary load-bearing structure composed of upper chord, lower chord and belly rod (diagonal bar and vertical bar).

Bracing:

Longitudinal connection system (upper and lower horizontal) withstands transverse loads
Transverse connection (bridge frame and crosslink) increases torsional stiffness

Bridge Deck System: Composed of longitudinal beams and connections, transferring loads to the main truss.

Bridge Floor: Surface for vehicles and pedestrians, similar to steel beam bridges.

Key Advantages

Rapid construction with prefabricated components
High strength-to-weight ratio
Large span capability
Energy efficient construction
Aesthetic appearance
Excellent seismic performance
Customizable designs

Main Truss Categories

Triangular Truss: Simple structure with fixed design, easy to install and manufacture. OEM Pedestrian Truss Bridge With Painted Surface Protection Fast Construction 1

Diagonal Bar Truss: Features multiple bar specifications with large internal force in vertical rods. OEM Pedestrian Truss Bridge With Painted Surface Protection Fast Construction 2

K-shaped Truss: Shear force distributed to two diagonal rods, suitable for mounting/dismounting bridges. OEM Pedestrian Truss Bridge With Painted Surface Protection Fast Construction 3

Double-Vented Bar Truss: Ideal for large spans with short compression inclined rods for better buckling stability. OEM Pedestrian Truss Bridge With Painted Surface Protection Fast Construction 4

Applications

Railroad bridges (standard gauge and light rail systems)
Highway and road bridges
Pedestrian walkways

Evercross Steel Bridges Specifications

Product Range	Bailey bridge, Modular bridge, Truss Bridge, Warren bridge, Arch bridge, Plate bridge, Beam bridge, Box girder bridge, Suspension bridge, Cable-stayed bridge, Floating bridge
Design Spans	10M TO 300M Single span
Carriage Way	SINGLE LANE, DOUBLE LANES, MULTILANE, WALKWAY
Loading Capacity	AASHTO HL93.HS15-44, HS20-44, HS25-44, BS5400 HA+20HB, HA+30HB, AS5100 Truck-T44, IRC 70R Class A/B, NATO STANAG MLC80/MLC110, Truck-60T, Trailer-80/100Ton
Steel Grade	EN10025 S355JR S355J0/EN10219 S460J0/EN10113 S460N/BS4360 Grade 55C, AS/NZS3678/3679/1163/Grade 350, ASTM A572/A572M GR50/GR65, GB1591 GB355B/C/D/460C
Certificates	ISO9001, ISO14001, ISO45001, EN1090, CIDB, COC, PVOC, SONCAP
Welding	AWS D1.1/AWS D1.5, AS/NZS 1554 or equivalent
Bolts	ISO898, AS/NZS1252, BS3692 or equivalent
Galvanization Code	ISO1461, AS/NZS 4680, ASTM-A123, BS1706 or equivalent
