Single Span Temporary Truss Bridge Metal Truss Bridge Energy Saving

Name: Single Span Temporary Truss Bridge Metal Truss Bridge Energy Saving
Brand: EVERCROSS BRIDGE TECHNOLOGY (SHANGHAI) CO.,LTD.
SKU: COMPACT-200; COMPACT-100; CHINA 321 ; PB 100; LSB; GWD; DELTA; 450,etc
Price: 1,500.00 USD
Availability: InStock

Brand Name:	EVERCROSS
Model Number:	COMPACT-200; COMPACT-100; CHINA 321 ; PB 100; LSB; GWD; DELTA; 450,etc
MOQ:	negotiation
Price:	1000USD ~ 2000USD Per ton
Delivery Time:	negotiation
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CNAS; COC; PVOC; SONCAP; CIDB;FORM E;FORM L; FORM M, etc

Product Name:

Steel Truss Bridge

Material:

Prefabricate Steel

Spans:

Short And Medium Spans

Bridge Deck:

Composite Deck

Surface Protection:

Painted

Standard:

AISI, ASTM, BS, DIN, GB, JIS

Surface Finish:

Painted Or Galvanized

Size:

Customized Size

Packaging Details:

According to detailed order

Highlight:

Single Span Temporary Truss Bridge

Temporary Truss Bridge Energy Saving

Energy saving Metal Truss Bridge

Product Description

Single Span Temporary Truss Bridge Metal Truss Bridge Energy Saving

Product Specifications

Product Name	Steel Truss Bridge
Material	Prefabricate Steel
Spans	Short And Medium Spans
Bridge Deck	Composite Deck
Surface Protection	Painted
Standard	AISI, ASTM, BS, DIN, GB, JIS
Surface Finish	Painted or Galvanized
Size	Customized Size

Steel Truss Bridge Overview

The steel truss bridge is a structural system combining beam and arch elements, featuring an integrated upper beam structure and lower pressure-bearing columns. This rigid connection creates a compression-bending and thrust structure that efficiently distributes loads.

Structural Components

Main Girder: Primary load-bearing structure composed of upper chord, lower chord, and belly rods (diagonal and vertical bars). Nodes are categorized as large or small with defined pitch distances.

Bracing: Includes longitudinal and horizontal connections that stabilize the structure against lateral loads. The system enhances torsional stiffness and adjusts force distribution.

Bridge Deck System: Comprises longitudinal beams and transverse beams that transfer loads from the deck to the main truss.

Bridge Floor: The walking surface for vehicles and pedestrians, similar to other steel beam bridge designs.

Key Advantages

Large span capability
Energy efficient design
Excellent seismic performance
Wide range of applications
Fully customizable configurations

Truss Categories

Triangular Truss: Simple structure with fixed design for easy installation and manufacturing. Single Span Temporary Truss Bridge Metal Truss Bridge Energy Saving 1

Diagonal Bar Truss: Features multiple bar specifications with large nodes and vertical rod forces. Single Span Temporary Truss Bridge Metal Truss Bridge Energy Saving 2

K-Shaped Truss: Shear force distribution through two diagonal rods, ideal for mounting/dismounting bridges. Single Span Temporary Truss Bridge Metal Truss Bridge Energy Saving 3

Double-Vented Bar Truss: Efficient for large spans with short compression rods that enhance buckling stability. Single Span Temporary Truss Bridge Metal Truss Bridge Energy Saving 4

Applications

Steel truss bridges serve diverse purposes including emergency/temporary crossings, river and waterway spans, and railroad bridges. Selection depends on span length, load requirements, and site conditions.

Evercross Steel Bridges Specifications

Category	Specifications
Bridge Types	Bailey bridge, Modular bridge, Truss Bridge, Warren bridge, Arch bridge, Plate bridge, Beam bridge, Box girder bridge, Suspension bridge, Cable-stayed bridge, Floating bridge
Design Spans	10M to 300M Single span
Carriage Way	Single lane, Double lanes, Multilane, Walkway
Loading Capacity	AASHTO HL93, HS15-44 to HS25-44, BS5400 HA+20HB to HA+30HB, AS5100 Truck-T44, IRC 70R Class A/B, NATO STANAG MLC80/MLC110, Truck-60T, Trailer-80/100Ton
Steel Grade	Various international standards including EN10025, AS/NZS3678, ASTM A572, GB1591
Certifications	ISO9001, ISO14001, ISO45001, EN1090, CIDB, COC, PVOC, SONCAP
