Customized Bailey Bridge Pier Steel Girder Railway Bridge

Name: Customized Bailey Bridge Pier Steel Girder Railway Bridge
Brand: EVERCROSS BRIDGE TECHNOLOGY (SHANGHAI) CO.,LTD.
SKU: COMPACT-200; COMPACT-100; CHINA 321 ; PB 100; LSB; GWD; DELTA; 450,etc
Price: 1,500.00 USD
Availability: InStock

Brand Name:	Evercross
Model Number:	COMPACT-200; COMPACT-100; CHINA 321 ; PB 100; LSB; GWD; DELTA; 450,etc
MOQ:	negotiation
Price:	1000USD ~ 2000USD Per ton
Delivery Time:	negotiation
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CNAS; COC; PVOC; SONCAP; CIDB;FORM E;FORM L; FORM M, etc

Product Name:

Bailey Bridge Pier

Loading Standard:

Hl93/Ha+20hb/T44/Class A/B/MLC110/dB24

Steel Grade:

S355/ S460/Gr 55c/Gr350/Gr50/Gr65/GB355/460

Stress Characteristics:

Truss Bridge

Application:

Over Water Bridge, Tractor Bridge, Pontoon, Footbridge, Public Iron Dual Purpose Bridge, Highway Bridge

Standard:

AISI, ASTM, BS, DIN, GB, JIS

Packaging Details:

According to detailed order

Highlight:

Customized Bailey Bridge Pier

Railway Bridge Bailey Bridge Pier

Steel Girder Bailey Bridge Pier

Product Description

Customized Bailey Bridge Pier Steel Girder Railway Bridge

Product Name	Bailey Bridge Pier
Loading Standard	Hl93/Ha+20hb/T44/Class a/B/MLC110/dB24
Steel Grade	S355/ S460/Gr 55c/Gr350/Gr50/Gr65/GB355/460
Stress Characteristics	Truss Bridge
Application	Over Water Bridge, Tractor Bridge, Pontoon, Footbridge, Public Iron Dual Purpose Bridge, Highway Bridge
Standard	AISI, ASTM, BS, DIN, GB, JIS

Bailey Bridge Pier Overview

The Bailey bridge pier consists of foundation, pier body, top support and bridge span fixing device. The foundation includes a base plate and anchor bolts, while the pier is composed of 1m truss, angle brace, HD321 Bailey panel standard truss, vertical cross braces, and horizontal wind structure.

These piers serve as critical support structures that hold up the bridge deck and efficiently transfer the weight of the bridge and all crossing loads down to the ground or riverbed below.

Key Components

Trestle Legs: Vertical supports made of durable steel or aluminum, available in various lengths to accommodate different terrain and water depths.

Chesses: Wooden or steel deck planks laid perpendicular across transom beams to create a stable traversable surface.

Sway Bracing: Diagonal steel rods or cables that connect trestle legs, providing essential lateral stability.

Key Features

The Bailey bridge pier design offers exceptional adaptability and versatility for temporary crossings in challenging environments. Its portability and rapid assembly were crucial factors in its widespread military and civilian use.

Lightweight Materials: Constructed from high-strength steel or aluminum for optimal strength-to-weight ratio.

Rapid Assembly: Modular design enables quick erection without specialized tools or equipment.

Standardized Components: Limited number of standardized parts simplifies maintenance and field repairs.
