Large Load Bailey Bridge Pier With Long Life Painted Surface

Name: Large Load Bailey Bridge Pier With Long Life Painted Surface
Brand: EVERCROSS BRIDGE TECHNOLOGY (SHANGHAI) CO.,LTD.
SKU: COMPACT-200; COMPACT-100; CHINA 321 ; PB 100; LSB; GWD; DELTA; 450,etc
Price: 1,500.00 USD
Availability: InStock

Brand Name:	Evercross
Model Number:	COMPACT-200; COMPACT-100; CHINA 321 ; PB 100; LSB; GWD; DELTA; 450,etc
MOQ:	negotiation
Price:	1000USD ~ 2000USD Per ton
Delivery Time:	negotiation
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CNAS; COC; PVOC; SONCAP; CIDB;FORM E;FORM L; FORM M, etc

Product Name:

Bailey Bridge Pier

Loading Standard:

Hl93/Ha+20hb/T44/Class A/B/MLC110/dB24

Steel Grade:

S355/ S460/Gr 55c/Gr350/Gr50/Gr65/GB355/460

Stress Characteristics:

Truss Bridge

Application:

Over Water Bridge, Tractor Bridge, Pontoon, Footbridge, Public Iron Dual Purpose Bridge, Highway Bridge

Standard:

AISI, ASTM, BS, DIN, GB, JIS

Packaging Details:

According to detailed order

Highlight:

Long Life Bailey Bridge Pier

Painted Surface Bailey Bridge Pier

Large Load Bailey Bridge Pier

Product Description

Large Load Bailey Bridge Pier With Long Life Painted Surface

Product Specifications

Attribute	Value
Product Name	Bailey Bridge Pier
Loading Standard	Hl93/Ha+20hb/T44/Class a/B/MLC110/dB24
Steel Grade	S355/ S460/Gr 55c/Gr350/Gr50/Gr65/GB355/460
Stress Characteristics	Truss Bridge
Application	Over Water Bridge, Tractor Bridge, Pontoon, Footbridge, Public Iron Dual Purpose Bridge, Highway Bridge
Standard	AISI, ASTM, BS, DIN, GB, JIS

Bailey Bridge Pier Overview

Bailey bridge piers serve as the critical support structures that hold up the bridge deck and efficiently transfer the weight of the bridge and all crossing loads to the ground or riverbed below.

Structural Components

Trestle Legs: Vertical supports made of durable steel or aluminum, available in various lengths to accommodate different depths
Chesses: Wooden or steel planks forming the deck surface, laid perpendicular across transom beams
Sway Bracing: Diagonal bracing members providing lateral stability and preventing sideways collapse
Transom Beams: Horizontal beams creating the support frame between trestle legs

Key Features

Lightweight Materials: Steel or aluminum construction reduces overall weight for easier transport and assembly
Rapid Assembly: Modular design enables quick erection without specialized tools
Standardized Components: Limited number of standardized parts simplifies maintenance and replacement

The HD321 Bailey pier utilizes 1m truss and HD321 Bailey panel standard truss as foundation components to form square column piers. The top support features beam staggered connections with space bar structures between piers, enhancing structural adaptability and material strength utilization while increasing stability.
