Simple Structure Steel Footbridge Steel Walking Bridge With Single Lane Long Life

Name: Simple Structure Steel Footbridge Steel Walking Bridge With Single Lane Long Life
Brand: EVERCROSS BRIDGE TECHNOLOGY (SHANGHAI) CO.,LTD.
SKU: COMPACT-200; COMPACT-100; CHINA 321 ; PB 100; LSB; GWD; DELTA; 450,etc
Price: 1,500.00 USD
Availability: InStock

Brand Name:	EVERCROSS
Model Number:	COMPACT-200; COMPACT-100; CHINA 321 ; PB 100; LSB; GWD; DELTA; 450,etc
MOQ:	negotiation
Price:	1000USD ~ 2000USD Per ton
Delivery Time:	negotiation
Payment Terms:	L/C, D/A, T/T, D/P, Western Union, MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CNAS; COC; PVOC; SONCAP; CIDB;FORM E;FORM L; FORM M, etc

Product Name:

Steel Modular Footbridge

Type:

PB 100

Load:

Pedestrian 3KN/m²

Panel Weight:

120kg

Sidewalk Net Width:

1.2m / 1.45m

The Maximum Single Span Of The Footbridge:

16m

Packaging Details:

According to detailed order

Highlight:

Simple Structure steel walking bridge

Single Lane Steel Footbridge

Simple Structure Steel Footbridge

Product Description

Simple Structure Steel Footbridge - Steel Walking Bridge With Single Lane Long Life

Attribute	Value
Product Name	Steel Modular Footbridge
Type	PB 100
Load	Pedestrian 3KN/m²
Panel weight	120kg
Sidewalk net width	1.2m / 1.45m
The maximum single span of the footbridge	16m

Simple Steel Modular Footbridge With Single Lane Long Life

PB100 Modular Footbridge Description

Modular footbridges are portable steel bridges that have been widely used in various fields. Their most important feature is the ability to achieve various spans while maintaining carrying capacity. The components are lightweight and handy, easy to dismantle, and offer strong adaptability for quick completion with simple tools and manpower. Surface protection can be paint or hot-dip galvanized.

Similar to other modular bridges, steel modular footbridges are assembled using pre-engineered components manufactured off-site. These components typically include steel trusses, decking panels, handrails, and other necessary structural elements. The prefabrication process allows for efficient manufacturing, quality control, and quick on-site assembly.

The Importance of Bailey Bridge Application on PB100 Modular Footbridge

Compared to general transportation and bridge construction, PB100 Modular footbridges have unique characteristics. They are economical and small-scale, providing connectivity for villagers in remote rural areas. These bridges are designed exclusively as footbridges, prohibiting vehicle and agricultural machinery use. Accordingly, the design loading for PB100 Modular footbridges is typically 3kN/m², significantly smaller than conventional bridges.

PB100 Modular Footbridge Origin

With smaller loading requirements, the structural members of the bailey panel were redesigned to be lighter weight, meeting economic, transportation, and construction needs. While ensuring safety, PB100 Modular footbridges overcome conventional Bailey bridge limitations and offer unique advantages for PB100 Modular footbridge projects.

After years of discussion and collaboration, PB100 Modular footbridges have applied Bailey bridge advantages and optimal material choices in their projects. The EVERCROSS team was entrusted to develop and design a lightweight PB100 Modular footbridge, considering functional demands, natural environmental conditions, technical feasibility, material transportation, and cost.

PB100 Modular Footbridge Introduction

Modular footbridges are lightweight footbridges constructed from fabricated steel. They consist of load-bearing bailey panels, minor load-carrying transoms (floor beams), decks, and other support members. Construction is simple using standardized prefabricated components within a reasonable budget.

Simple Structure Steel Footbridge Steel Walking Bridge With Single Lane Long Life 1

PB100 Modular Footbridge Features

High strength and stiffness, allowing reduced beam height and self-weight compared to concrete bridges
Steel's isotropic nature ensures uniform material quality and modulus of elasticity, making calculations more accurate
Prefabricated in factories and assembled on-site using pins and bolts; short construction period, convenient processing, and unaffected by seasons
Suitable for industrialized manufacture and easy transportation
Easy to repair and replace, long lifetime, with recyclable materials

Steel Trusses: The main load-bearing elements designed to support pedestrian and other loads while providing structural stability.

Lighting: Can incorporate lighting features for improved visibility and safety during nighttime use.

Corrosion Resistance: Typically treated with protective coatings or galvanized to enhance longevity and reduce maintenance.

PB100 Modular Footbridge Scope of Application

Bridge erection can be completed quickly using only manual labor and simple machinery. This versatile design is widely applicable as a footbridge in rural and mountainous areas.

Designed exclusively for pedestrians and livestock, not for vehicles or agricultural machinery. Two standard roadway widths (1300mm and 1500mm) are available, with the wider design suitable for livestock passage. The clear width limitation prevents overloading by vehicles.

Mixture Form to Erect All Kinds of PB100 Modular Footbridge

Applications include Temporary Bridges, Emergency Bridges, and Fixed Bridges. Suspension bridges of varied spans can be erected using this bridge equipment. The system offers advantages of few components, light weight, and low cost.

No special tools or heavy equipment are required for construction. The bridge elements are small enough to be carried in manually while being strong enough to support the required loads. This system represents an excellent example of military engineering.

PB100 Modular Footbridge Competitive Advantage

Light Structural Design: Based on standard bailey panel structure, with single panels weighing less than 120kg and 2 meters in length. This lightweight design enables application in various projects while lowering costs and preventing resource waste.

Convenient Transportation: Ideal for mountainous and rugged terrain where transportation conditions are often remote and rough. Lightweight components can be easily handled manually and assembled on-site.

Moderate Construction Difficulty: Simplified and standardized bridge structure and components require only simple tools and machinery, reducing the need for skilled personnel on-site.

Good Durability: Steel open sections prevent rainwater and dust accumulation. Zinc galvanization prevents rusting, improves durability, and avoids river pollution from traditional anti-rust paint.

Long Span: Longer spans than gabion bridges require fewer piers, minimizing riverbed disturbance and maintaining effective water flow.

PB100 Modular Footbridge Advantage

Simple structure
Standardization of prefabricated components
Controllable cost
Fast construction speed

Evercross Steel Bridges Overview

EVERCROSS STEEL BRIDGE	Bailey bridge(Compact-200, Compact-100, LSB, PB100, China-321,BSB) Modular bridge(GWD, Delta, 450-type,etc), Truss Bridge, Warren bridge, Arch bridge, Plate bridge, Beam bridge, Box girder bridge, Suspension bridge, Cable-stayed bridge, Floating bridge, etc
DESIGN SPANS	10M TO 300M Single span
CARRIAGE WAY	SINGLE LANE, DOUBLE LANES, MULTILANE, WALKWAY, ETC
LOADING CAPACITY	AASHTO HL93.HS15-44,HS20-44,HS25-44,BS5400 HA+20HB,HA+30HB,AS5100 Truck-T44,IRC 70R Class A/B,NATO STANAG MLC80/MLC110.Truck-60T,Trailer-80/100Ton,etc
STEEL GRADE	EN10025 S355JR S355J0/EN10219 S460J0/EN10113 S460N/BS4360 Grade 55CAS/NZS3678/3679/1163/Grade 350,ASTM A572/A572M GR50/GR65GB1591 GB355B/C/D/460C,etc
CERTIFICATES	ISO9001, ISO14001,ISO45001,EN1090,CIDB,COC,PVOC,SONCAP,etc
WELDING	AWS D1.1/AWS D1.5AS/NZS 1554 or equivalent
BOLTS	ISO898,AS/NZS1252,BS3692 or equivalent
GALVANIZATION CODE	ISO1461AS/NZS 4680ASTM-A123,BS1706or equivalent
